AirRohr

Benötigte Bauteile

LCSC Part Number	Manufacturer Part Number	Manufacturer	Package	Description	Order Qty.
C400087	CT4G-0805-2×1-63V-0.1μF-K	TORCH	Plugin,P=5.08mm	±10% 63V 100nF Multilayer Ceramic Capacitors MLCC	1
C263757	S5B-XH-A(LF)(SN)	JST Sales America	Push-Pull,P=2.5mm	1x5P XH 2.5mm Wire To Board Connector	1
C8465	WJ500V-5.08-2P	Ningbo Kangnex Elec	Plugin,P=5.08mm	1x2P 18A -40℃~+105℃ 250V Green 5.08mm Screw Terminal	1
C492401	PZ254V-11-02P	XFCN	Plugin,P=2.54mm	Straight Square Pins 2.5mm 1x2P 6mm -40℃~+105℃ Black Pin Headers	1
C350310	2685Y-104CNG1SNA01	HOAUC	Plugin,P=2.54mm	2.54mm 1x4P Straight Female Header	6
C265404	S5B-ZR(LF)(SN)	JST Sales America	Push-Pull,P=1.5mm	1x5P 1.5mm Wire To Board Connector	1
C77859	DS1133-S60BPX	CONNFLY Elec	Plugin	RJ12 RJReceptacle Ethernet Connector	1
C350294	2685Y-215CNG1SNA01	HOAUC	Plugin,P=2.54mm	2.54mm 2x15P Straight Female Header	2
C176501	MFR-25JT-52-330R	YAGEO	Plugin	Metal Film Resistor 330Ω 250mW ±5% Through Hole	2
C176521	MFR-25JT-52-4K7	YAGEO	Plugin	Metal Film Resistor 4.7kΩ 250mW ±5% Through Hole	2
C176451	MFR-25JT-52-10K	YAGEO	Plugin	Metal Film Resistor 10kΩ 250mW ±5% Through Hole	1
C2649394	P82B715DR	Texas Instruments	SOP-8	I2C SOP-8 2-WireBus Signal Buffers / Driver	1
C5274552	KH-2.54TXM-CB-H13.5-G	Shenzhen Kinghelm Elec	P=2.54mm	2.54mm Green Jumper with Grip	1

Description	Type	Order Qty.	Source
Nylon Spacer Black	M3x6mm	3	https://de.aliexpress.com/item/32976004197.html
Nylon Phillips Head Screw Black	M3x12mm	3	https://de.aliexpress.com/item/32976004197.html
Nylon Hex Nut Black	M3	3	https://de.aliexpress.com/item/32976004197.html
Aquaristikschlauch	Ø 6mm	1 x 20cm	https://toom.de/p/aquaristikschlauch-gruen-6-mm-1-m/4207104
HTB-Bogen	87° DN 75	2	https://toom.de/p/htb-bogen-87-dn-75/5650436
